Celero 4
MultiCam’s Celero 4 Series offers the industry’s best all-around cutter in price and performance.
Please consult your local sales manager for the availability of this product in your region.
Flatbed cutters
Celero 4
Taking innovation to the next level, this system is a powerful, versatile, and affordable choice, delivering high-speed production with knife cutting speeds up to 4,000 inches per minute (IPM). This multi-purpose cutter/router is specifically designed to meet the ever-growing needs of the signage, display, and packaging industries.
- High-speed cutting performance for increased throughput
- Flexible knife and routing capabilities for a wide range of materials
- Automated tool changing and vision technology to reduce manual intervention and improve productivity
Capabilities
Built to handle a wide range of materials
Cut, route, automate tool changes, process roll-fed materials, and maintain accuracy with integrated vision technology.
Tool Carriage
Whether your application requires just knife cutting, or a variety of applications requiring knife, oscillating, and routing, the configurable tool carriage allows you to select the perfect combination of tools to meet your application specifics.
Quiet operation
The Celero 4 Series comes standard with a 5.1HP vacuum blower with four pneumatically controlled vacuum zones, providing minimal noise levels of between 60dB – 75dB.
Router Spindle
The Celero 4 Series features a 3HP, 24,000 RPM spindle which allows for a wide range of routing applications. Whether routing acrylic, dibond or any other dense substrates, you will experience quality cuts part after part.
4HP Spindle & Auto Tool Changer
An optional 4HP spindle upgrade is available with an Automatic Router Bit Changer that holds up to five different router bits. Designed for routing applications that require multiple tools, the system automatically changes bits without operator intervention, reducing setup time and supporting unattended operation. Combined with the Celero 4's Automatic Knife Changer, this capability increases productivity and workflow flexibility for complex routing applications, including 3D engraving and other multi-tool jobs.
MultiVision
MultiVision provides end-users additional flexibility as the camera system is able to visually recognize media registration marks and automatically compensate for skew and/or image drift.
Auto knife changer
An industry first linear knife tool changer allows you to automate your knife changing and eliminate costly errors of manual operations. The Celero 4322 comes standard with five automatic knife tool locations.
Material conveyor
The Celero 4 Series comes equipped with a conveyor capable of handling up to 10’ flexible media and has the width to handle oversized substrates up to 10’ x 6.6”. It can be used for cutting single pieces or multiple runs for applications like banners, labels, packaging, or textiles.
Servo drive system
The Celero 4 Series comes standard with a robust drive motor system with servo drives to allow for powerful fluid motion.
features
The Technology Behind the Celero 4
Specifications
- Z-Axis clearance: 2” (50 mm)
- Z-Axis Travel: 6.5″ (165 mm)
- Cut speed: 4,000 IPM
- Rapid traverse: 5,656 IPM (101,5 m / min)
- Repeatability: +/- 0.001” (0,025 mm)
- Drive System (X,Y): Helical
- Drive System (Z): Ball Screw
- Work Surface: 1.25″ (31,75 mm) phenolic
- (Specifications subject to change without notice)
Applications
- Point of purchase display
- Sign making
- Packaging
- Textiles
- Aluminum cutting
- Digital print
- Vinyl banners
- Vehicle wraps
- Acrylic display
- Leather goods
- 3-Dimensional signs
See how it works
Celero 4
This video highlights the Celero 4 in action, showcasing the speed, versatility, and productivity that make it an ideal solution for signage, display, and packaging applications. With knife cutting speeds up to 4,000 IPM and the ability to combine cutting and routing in a single system, the Celero 4 helps businesses handle a wide range of production requirements efficiently and cost-effectively.
Before you ask
Frequently askes questions
What is a digital flatbed cutter used for?
What is a digital flatbed cutter used for?
A digital flatbed cutter is used to cut, crease and route a wide range of materials for applications such as signage, displays, packaging, textiles, digital print and graphics production.
What materials can a flatbed cutter process?
What materials can a flatbed cutter process?
Flatbed cutters can process a wide variety of rigid and flexible materials, including cardboard, foam, corrugated plastic, acrylic, vinyl, PVC, textiles, leather and wood. The materials that can be processed depend on the machine and tooling configuration.
What are the benefits of digital flatbed cutting?
What are the benefits of digital flatbed cutting?
Digital flatbed cutting combines versatility, accuracy and efficient production without requiring physical cutting dies. Different tools and processes can be used to handle various materials and applications on one cutting system.
How does a flatbed cutter improve production efficiency?
How does a flatbed cutter improve production efficiency?
A flatbed cutter can streamline production by combining multiple cutting processes within a digital workflow. Features such as automated tool changing, vision systems and material handling can further reduce manual intervention and support efficient production.
What can the Celero 4 flatbed cutter do?
What can the Celero 4 flatbed cutter do?
The Celero 4 combines high-speed knife cutting and routing in one digital flatbed cutting system. Its configurable tooling supports a wide range of rigid and flexible materials for signage, display, packaging and textile applications.
