Performance
Accurate cutting for a wide range of materials
The MultiCam 1000 Series CNC Waterjet is an economical water-only cutting solution for businesses that need accurate, quality cutting across a wide range of thin materials. It combines reliable performance with a simple workflow, making it suitable for both novice and experienced operators.
capabilities
Everything you need for versatile, efficient production
Simple yet effective workflow
MultiCam's EZ Control G-Code and Coreo software ensures a simple yet effective workflow for machine novice and experienced operators alike.
- EZ Control G-Code and Coreo software
- Suitable for novice and experienced operators
- Draw, program, and cut within the same program
Combined with Coreo, an intuitive CAD/CAM software, businesses will have the ability to draw, program, and cut within the same program.
Maximize production output
With a cut speed of 1,000 IPM and a rapid traverse of 1,200 IPM, the 1000 Series Waterjet provides quality and reliable cutting.
- Cut speed of 1,000 IPM
- Rapid traverse of 1,200 IPM
- Quality and reliable cutting
Since the jet-stream of water is so small, the kerf (line of cut) is minimized so businesses can get the most parts out of their material to maximize production output.
Say yes to endless possibilities
The 1000 Series Waterjet can cut a wide range of materials, including:
- Rubber
- Foam
- Vinyl
- Textile
The 1000 Series CNC waterjet makes your company a trustworthy production partner in applications such as automotive fabrication, aerospace, gaskets, sign making, and the food industry.
Features
1000 Series Waterjet
The perfect platform for accurate and quality cuts.
Basic information
- 30 HP
- Table sizes: 60″ x 120″ to 80″ x 144″ (152 cm x 305 cm to 203 cm x 365 cm)
- Rapid Traverse: 1,200 IPM (30,5 m / min)
- Repeatability: +/- 0.001″ (0,025 mm)
Standard features
- MultiCam EZ Control®, Coreo® BMO software
- All-steel, stress- relieved, integral water tank design
- Three-side cutting tank access
- Integrated fork lift tubes
- Dual-side, brushless digital AC servo drives
- Full range of KMT intensifiers
- (Features subject to change without notice)
Options
- Two and three head configurations
- Up to four pure water heads
- CNC Computer Interface Station
- Integrated CNC control air conditioner
- Laser Pointer
- MultiCam Coreo software packages
- Chiller for intensifier
- Closed-loop filtration system
- (Options subject to change without notice)
Specifications
- 25mm linear bearing profile rails
- Z-axis clearance: 4.5” (11,5 cm)
- Z-axis travel: 6” (15 cm)
- Cut speed: 1,000 IPM (25,5 m / min)
- Rapid traverse speed: 1,200 IPM (30,5 m / min)
- Repeatability: +/- 0.001” (0,025 mm)
- Drive system X and Y axis: Linear rack and pinion
- Drive system Z axis: Lead screw
- (Specifications subject to change without notice)
Services
Premium service nearby!
When you choose to invest in our cnc waterjet cutters, you also get MultiCam’s amazing customer service.
With more than 70 locations in our global network of experts, MultiCam customer service is easy to access when you need help.
Before you ask
Frequently asked questions
What materials can the MultiCam 1000 Series CNC Waterjet cut?
What materials can the MultiCam 1000 Series CNC Waterjet cut?
The MultiCam 1000 Series CNC Waterjet can cut a wide range of thin materials, including rubber, foam, vinyl and textile. Its water-only cutting process makes it suitable for many heat-sensitive materials and applications.
What are the benefits of waterjet cutting?
What are the benefits of waterjet cutting?
Waterjet cutting delivers accurate cuts without creating a heat-affected zone. This helps prevent heat-sensitive materials from warping or being damaged during cutting, while the narrow kerf helps maximize material yield.
Does waterjet cutting create a heat-affected zone?
Does waterjet cutting create a heat-affected zone?
No. Waterjet cutting does not create a heat-affected zone because the cutting process does not rely on heat. This makes it particularly suitable for materials that can be affected by high temperatures.
How fast can the MultiCam 1000 Series CNC Waterjet cut?
How fast can the MultiCam 1000 Series CNC Waterjet cut?
The MultiCam 1000 Series CNC Waterjet offers cutting speeds of up to 1,000 IPM and rapid traverse speeds of up to 1,200 IPM for efficient, reliable production.
Is the MultiCam 1000 Series CNC Waterjet easy to operate?
Is the MultiCam 1000 Series CNC Waterjet easy to operate?
Yes. The 1000 Series combines MultiCam’s EZ Control G-Code interface with Coreo CAD/CAM software for a straightforward workflow. Operators can draw, program and cut within the same software environment.
